- 产品详情
| 产品特色 | |
| 符合LED、医疗安全认证 2 MOPP 隔离保护 DOE Efficiency Level VI CoC V5 Tier2(2016) PF>0.95@230VAC满载漏电流 ≤ 100μA 待机功耗≤0.15W 工作海拨高度5000米 |
| 电气规格 | |
| 输入电压 | 80-264VAC |
| 频率范围 | 47-63Hz |
| 输入电流 | 2.0A,在80VAC输入条件下 |
| 浪涌电流 | 120A最大,在240VAC输入和冷启动条件下 |
| 接触电流 | ≤ 100μA 在264VAC输入条件下 |
| 环境 | 一般 | ||
| 工作温度 | -10~40℃ | 外形尺寸 | 145.1(长)x69.5(宽)x24.25(高)mm |
| 储存温度 | -20〜60℃ | 重量 | 450g |
| 工作湿度 | 10〜90％RH, 非冷凝 | 平均故障间隔时间 | > 100,000小时MIL-HDBK-217，在25℃环境温度下。 |
| 储存湿度 | 5〜90％RH | 隔离耐压强度 | 5,656VDC 输入到输出 |
| 工作海拔高度 | 5000m |
| 安规认证 | ||
| 安规机构/标志 | 医疗 | 通信 |
| CB | IEC60601-1 / IEC60601-1-11 | IEC62368-1 |
| CCC | - | GB4943.1 |
| UL | ANSI/AAMI ES60601-1/60601-1-11 | UL62368 |
| CAN/CSA-C22.2 NO. 60601-1 | ||
| TUV-SUD/Mark | EN60601-1/EN60601-1-11 | - |
| TUV-SUD/GS | - | EN62368-1 |
| CE | - | EN62368 |
| PSE | - | J62368 |
| KC | - | K60950-1 |
| BSMI | - | CNS14436 |
输出数据
| 型号 | 电压 | 电流 | 额定功率 | 纹波及噪音 | 电压公差 | 线性与负载 | 平均效率 | 启动延迟时间 |
| （V） | （A） | （最大） | 调整率 | |||||
| DPS120DZ-XXXYYYSPA | 11.0-12.0 | 0.01-10.0 | 120W | 150mVpk-pk | ±5% | 线性调整率: ±1% 负载调整率: ±5% | 92.00% | ≤3s |
| 12.1-13.0 | 0.01-9.23 | 120W | 150mVpk-pk | ±5% | 92.00% | ≤3s | ||
| 13.1-14.0 | 0.01-8.57 | 120W | 150mVpk-pk | ±5% | 92.00% | ≤3s | ||
| 14.1-15.0 | 0.01-8.00 | 120W | 150mVpk-pk | ±5% | 92.00% | ≤3s | ||
| 17.1-18.0 | 0.01-6.66 | 120W | 180mVpk-pk | ±5% | 93.00% | ≤3s | ||
| 18.1-19.0 | 0.01-6.31 | 120W | 180mVpk-pk | ±5% | 93.00% | ≤3s | ||
| 19.1-20.0 | 0.01-6.00 | 120W | 200mVpk-pk | ±5% | 93.00% | ≤3s | ||
| 20.1-21.0 | 0.01-5.71 | 120W | 200mVpk-pk | ±5% | 93.00% | ≤3s | ||
| 21.1-22.0 | 0.01-5.45 | 120W | 200mVpk-pk | ±5% | 93.00% | ≤3s | ||
| 22.1-23.0 | 0.01-5.21 | 120W | 200mVpk-pk | ±5% | 93.00% | ≤3s | ||
| 23.1-24.0 | 0.01-5.00 | 120W | 240mVpk-pk | ±5% | 93.00% | ≤3s | ||
| 24.1-25.0 | 0.01-4.80 | 120W | 240mVpk-pk | ±5% | 93.00% | ≤3s | ||
| 25.1-26.0 | 0.01-4.61 | 120W | 240mVpk-pk | ±5% | 93.00% | ≤3s | ||
| 26.1-27.0 | 0.01-4.44 | 120W | 240mVpk-pk | ±5% | 93.00% | ≤3s | ||
| 35.1-36.0 | 0.01-3.33 | 120W | 300mVpk-pk | ±5% | 94.00% | ≤3s | ||
| 36.1-37.0 | 0.01-3.24 | 120W | 300mVpk-pk | ±5% | 94.00% | ≤3s | ||
| 37.1-38.0 | 0.01-3.15 | 120W | 300mVpk-pk | ±5% | 94.00% | ≤3s | ||
| 38.1-39.0 | 0.01-3.07 | 120W | 300mVpk-pk | ±5% | 94.00% | ≤3s | ||
| 39.1-40.0 | 0.01-3.00 | 120W | 300mVpk-pk | ±5% | 94.00% | ≤3s | ||
| 47.1-48.0 | 0.01-2.50 | 120W | 400mVpk-pk | ±5% | 94.00% | ≤3s | ||
| 48.1-49.0 | 0.01-2.44 | 120W | 400mVpk-pk | ±5% | 94.00% | ≤3s | ||
| 49.1-50.0 | 0.01-2.40 | 120W | 400mVpk-pk | ±5% | 94.00% | ≤3s | ||
| 50.1-51.0 | 0.01-2.35 | 120W | 400mVpk-pk | ±5% | 94.00% | ≤3s | ||
| 51.1-52.0 | 0.01-2.30 | 120W | 400mVpk-pk | ±5% | 94.00% | ≤3s | ||
| 52.1-53.0 | 0.01-2.26 | 120W | 400mVpk-pk | ±5% | 94.00% | ≤3s | ||
| 53.1-54.0 | 0.01-2.22 | 120W | 400mVpk-pk | ±5% | 94.00% | ≤3s |
